DC injector IDCI
DC injector IDCI is two way DC Injector supplies LNB and/or BUC with VDC via radio-frequency cablе from a single power source.
Developed for indoor.
 UMT LLC.jpg)
 UMT LLC.jpg)
- Description
- Downloads
| Parameter | Value |
|---|---|
| Frequency range, MHz | 950-2150 |
| Impedance & type of RF connectors, Ohm | 50Ω (N-type); 75Ω (F-type) |
| Supply voltage, VDC (up to) | 24 |
| Maximum current, A (total) | 4 |
| Insertion loss, dB | <1.0 (full band) |
| Flatness, dB | ± 0.5 (full band) ± 0.2 (any 36MHz) |
| Return loss, dB | 17 |
| Dimensions, mm | 115х45х80 |
| Weight, kg | 0.15 |
Taking into consideration that we (UMT LLC) are developer and system integrator, also do not stop on our technical growth and improvement, know that view of all our devices and equipment including their technical parameters may be different from pictures presented on website and parameters listed on each device webpage.
Note! All details customer has to confirm in advance during ordering and before payment. Those parameters that were not specified and / or were not agreed while ordering will be implemented as basic at the discretion of the manufacturer. Each our customer has 1.5 year warranty and 7 year aftersales support for whole range of our products.
