7ch with CI slots DVB-S2 IRD
7ch with CI slots DVB-S2 IRD is multichannel Professional Integrated Receiver and Descrambler designed for high-quality TV broadcasting. It can demodulate and descramble up to 7 channels by integrated 7 DVB-S/S2 satellite tuners with CI slots.
 UMT LLC.jpg)
- Description
- Downloads
7ch with CI slots DVB-S2 IRD has 7 independent DVB-S/S2 tuners for receiving RF signals. For descrambling the 7 CI slots for CAM and CAS card are provided. Each channel has its own ASI output for further TS transmission via coaxial cable. In the same time 7ch with CI slots DVB-S2 IRD has 3 ASI outputs after integrated remultiplexer and a number of IP outputs (UDP/RTP protocols, the so called mirrored IP outputs according to ASI outputs).
KEY FEATURES:
- Integrated 7 satellite tuner channels (DVB-S/S2 standard) with CI slots;
- PCMCIA DVB-CI port, support single/multiple decoding;
- Supported international general CAS: Conax, Cryptoworks, Irdeto, NDS, Mediaguard, SECA, Viaccess, etc.;
- Supported ASI program remultiplex;
- Included TSoIP (TS over IP 1000Mbit/s output);
- TS package formats: 188/204 bytes (automatic);
- To save working condition of last time, device can automatically start to the right status after power recovery;
- Support PSI/SI editing and insertion
| Input/Output | |
|---|---|
| Input Channel | Demodulation: 7 satellite tuner channels (DVB-S/S2) |
| Output Channel | Each tuner has independent ASI output, SMB; |
| 3 groups of ASI output after multiplexing, each group includes 2 SMB; | |
| TSoIP (option) | |
| PID Remap | 384 (each channel 128) |
| Function | • PID Remap (manual or automatic) |
| • PCR precise adjustment | |
| • Automatically generate PSI/SI form | |
| DVB-S/S2 Tuner | |
| Input Frequency Range | 950 MHz ~ 2150 MHz |
| Demodulation | QPSK/8PSK, MPTS/SPTS |
| FEC | • DVB-S2 8PSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 |
| • DVB-S QPSK: 1/2, 2/3, 3/4, 5/6, 7/8 | |
| Symbol Rate | • QPSK/LDPC/BCH: 1MSps~55MSps |
| • 8PSK/LDPC/BCH: 1MSps~45MSps | |
| • DVB QPSK: 1MSps~55MSps | |
| Input Level | -65dBm ~ -25dBm |
| LNB Power Supply | 13V/17V. For maximum of 4 channels at the same time |
| Descrambling | |
| Descramble Processing | DVB-CSA |
| Smart Card Port | Adopt ISO7816 standard |
| Slot port | PCMCIA |
| Multiplexing | |
| • Multiplex to 3 or 8 TS output after scrambled (it depends on TSoIP option) | |
| • Each channel supports ES PID up to 128 | |
| • 3 groups of ASI out, each group has 2 SMB ports. When TSoIP is selected, each group of ASI can select one IP streaming from the total 8 channels TSoIP to output (the output of the three groups of ASI can be the same or different 2 or 3 channels) | |
| • Support TDT generating & insertion | |
| TSoIP (option) | |
| • 8 IP output (MPTS or SPTS) | |
| • 57 IP-TS input (MPTS or SPTS) | |
| • RTP/UDP | |
| • 10/100M/1000M Ethernet | |
| System | |
| English Operation Interface | |
| Support network upgrade | |
| • 10/100M Ethernet | |
| • RJ45 | |
| Structure | |
| Temperature Range | 0～45°C (working) ; -20～80°C (storage) |
| Power Supply | AC 100 V±10%, 50/60 Hz AC 220 V±10%, 50/60 Hz |
| Consumption | 75 W |
| Size (mm, W x H x D) | 440 x 44 x 460 |
| Weight | TBD |
